Helium Liquefiers

Automated 80 and 160 litre capacity helium liquefiers

Quantum Design’s Advanced Technology liquefiers (ATL) allow you to recover the helium gas currently being
lost from the normal boil off and helium transfers of your cryogenic instruments. They do this along with their
innovative helium recovery, storage and purification systems.
ATL160
• Average liquefaction rate: 22 litres/day (0.92 litres/hr)*
• Dewar capacity: 160 litres
• Fully automated touch panel control
Features:
• Easy to use, fully automated operation
• Portable liquefiers for easy transfers
• High liquefaction rates; energy efficiency
• Self cleaning, uninterrupted service
• Modular design: Your system can grow as your helium needs evolve CRYOGENICS

Helium recovery options: allows recovery, storage and purification of helium from normal and
transfer boil off.
• Direct recovery system: The most simple recovery system. Either ATL model can be used with
customer instrument to reclaim helium lost through normal boil off.
• Recovery system with medium pressure storage: Ideal for users with one or two cryogenic
instruments.
• Recovery system with high pressure storage: Ideal for users with multiple cryogenic instruments
or large, multi-room laboratories.
* Liquefaction rates vary based on transfer frequency, input helium quality and pressure.
